Table 8-4: ADSP-SC58x Trigger List Slaves (Continued)
Trigger ID
Name
40
HAE0_RXDMA_CH1
41
HAE0_TXDMA
42
SINC0_SYNC0
43
SINC0_SYNC1
44
FFTA0_TXDMA
45
FFTA0_RXDMA
46
EPPI0_CH0_DMA
47
EPPI0_CH1_DMA
48
LP0_DMA
49
LP1_DMA
50
RCU0_SYSRST0
51
RCU0_SYSRST1
52
STM0_EVT0
53
STM0_EVT1
54
STM0_EVT2
55
STM0_EVT3
56
STM0_EVT4
57
STM0_EVT5
58
STM0_EVT6
59
STM0_EVT7
60
STM0_EVT8
61
STM0_EVT9
62
STM0_EVT10
63
STM0_EVT11
64
STM0_EVT12
65
STM0_EVT13
66
STM0_EVT14
67
STM0_EVT15
68
STM0_EVT16
69
STM0_EVT17
70
STM0_EVT18
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
HAE0 RX DMA Channel 1
HAE0 TX DMA Channel 0
SINC0 Synchronization Input 0
SINC0 Synchronization Input 1
FFTA0 Transmit DMA
FFTA0 Receive DMA
EPPI0 Channel 0 DMA
EPPI0 Channel 1 DMA
LP0 DMA Channel
LP1 DMA Channel
RCU0 System Reset 0
RCU0 System Reset 1
STM0 Event 0
STM0 Event 1
STM0 Event 2
STM0 Event 3
STM0 Event 4
STM0 Event 5
STM0 Event 6
STM0 Event 7
STM0 Event 8
STM0 Event 9
STM0 Event 10
STM0 Event 11
STM0 Event 12
STM0 Event 13
STM0 Event 14
STM0 Event 15
STM0 Event 16
STM0 Event 17
STM0 Event 18
TRU Functional Description
Sensitivity
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
Pulse
8–9
