ADSP-SC573 EZ-KIT
Manual
Revision 1.0, June 2016
Part Number
82-000760-01
Analog Devices, Inc.
One Technology Way
Norwood, MA 02062-9106
Arrow.com.
Downloaded from

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSP-SC573 EZ-KIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Analog Devices ADSP-SC573 EZ-KIT

Summary of Contents for Analog Devices ADSP-SC573 EZ-KIT

  • Page 1 ® ADSP-SC573 EZ-KIT Manual Revision 1.0, June 2016 Part Number 82-000760-01 Analog Devices, Inc. One Technology Way Norwood, MA 02062-9106 Arrow.com. Downloaded from...
  • Page 2 Regulatory Compliance The ADSP-SC573 EZ-KIT is designed to be used solely in a laboratory environment. The board is not intended for use as a consumer-end product or as a portion of a consumer-end product. The board is an open system design, which does not include a shielded enclosure and, therefore, may cause interference to other electrical devices in close proximity.
  • Page 3 The ADSP-SC573 EZ-KIT contains ESD (electrostatic discharge) sensitive devices. Electrostatic charges readily accu- mulate on the human body and equipment and can discharge without detection. Permanent damage may occur on devices subjected to high-energy discharges. Proper ESD precautions are recommended to avoid performance degra- dation or loss of functionality.

  • Page 4: Table Of Contents

    Manual Contents ............................1–2 Technical Support ............................1–2 Supported Processors ............................. 1–3 Supported Tools............................. 1–3 Product Information ............................1–3 Analog Devices Website..........................1–3 EngineerZone ............................. 1–4 Notation Conventions ........................... 1–4 Using the Board Product Overview ............................2–1 Package Contents............................2–3 Default Configuration ...........................
  • Page 5 ) ................... 3–11 SW4, SW3 and SW9 Rotary Encoder ( )..........................3–11 CAN Wake ( ) ........................... 3–11 JTAG Interface ( ) ......................3–12 SW6 and SW7 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from...
  • Page 6 ) ..........................3–19 S/PDIF Digital ( ) ..........................3–19 MLB ( )............................. 3–19 Headphone ( ) ........................... 3–19 HADC ( ) ........................ 3–20 J15-J17 and J19 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from...
  • Page 7 Power Plug ( ) ........................... 3–21 USB ( ).............................. 3–21 Power Terminal Block ( )........................3–21 Expansion Interface 3 ( )..................3–22 P1A, P1B and P1C ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from...

  • Page 8: Preface

    SHARC+ dual-core and the ARM Cortex-A5TM core. The ADSP-SC573SHARC processor is a members of the SIMD SHARC family of DSPs that feature Analog Devices Super Harvard Architecture. These 32- bit/40- bit/64-bit floating-point processors are optimized for high performance audio/floating-point applications with their large onchip SRAM, multiple internal buses to eliminate I/O bottlenecks, and innovative digital audio interfaces (DAI).

  • Page 9: Manual Contents

    Manual Contents For additional information about the Analog Devices processor, see the Hardware Reference Manual. The document describes the core and memory architecture of the ADSP-SC57xprocessor, but does not provide detailed program- ming information. The applicable documentation for programming the SHARC+ and ARM Cortex-A5 core includes: •...

  • Page 10: Supported Processors

    Norwood, MA 02062-9106 Supported Processors This evaluation system supports the Analog Devices ADSP-SC573 processor. Supported Tools Information about code development tools for the ADSP-SC573 EZ-KIT and ADSP-SC57x family of processors is available at: http://www.analog.com/SC573EZKIT Product Information Product information can be obtained from the Analog Devices Website and CCES online help.

  • Page 11: Engineerzone

    If you are a registered user, just log on. Your user name is your e-mail address. EngineerZone EngineerZone is a technical support forum from Analog Devices, Inc. It allows you direct access to ADI technical support engineers. You can search FAQs and technical information to get quick answers to your embedded process- ing and DSP design questions.
  • Page 12 A warning identifies conditions or inappropriate usage of the product that could lead to conditions that are potentially hazardous for devices users. In the online version of this book, the word ATTENTION: appears instead of this symbol. ® 1–5 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com.

  • Page 13: Using The Board

    This chapter provides information on the major components and peripherals on the board along with instructions for installing and setting up the emulation software. Product Overview The board features: • Analog Devices ADSP-SC573 processor • 400 ball BGA • 25 MHz oscillator • DDR3 Memory •...
  • Page 14 Product Overview • Two RJ45 connectors • Audio • Analog Devices 12 Channel, High Performance, 192kHz, 24-Bit DAC (ADAU1962A) • Analog Devices Quad ADC with Diagnostics (ADAU1977) • Analog Devices Quad Analog-to-Digital Converter (ADAU1979) • 12 RCA connectors. 12 outputs or 8 outputs/4 inputs •...

  • Page 15: Package Contents

    • Ethernet Cable • SD Memory Card • ICE-1000 emulator Contact the vendor where you purchased your ADSP-SC573 EZ-KIT or contact Analog Devices, Inc. if any item is missing. Default Configuration The ADSP-SC573 EZ-KIT board is designed to run as a standalone unit.

  • Page 16: Crosscore Embedded Studio Setup

    PC. NOTE: If you connect the board or emulator first (before installing CCES) to the PC, the Windows driver wizard may not find the board drivers. 2–4 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com.

  • Page 17: Debug Interface

    • The Select Platform page of the Session Wizard appears. • Choose the type of emulator that is connected to the ADSP-SC573 EZ-KIT . • Click Finish to close the wizard. The new debug configuration is created and added to the Debug Configura- tions list.

  • Page 18: Power Measurements

    Refer to a readme file provided with each example for more information. Reference Design Information A reference design info package is available for download on the Analog Devices Web site. The package provides information on the schematic design, layout, fabrication, and assembly of the board.

  • Page 19: Automotive Audio Bus A B Transceiver (Ad2410)

    By using the on-board PLL to derive the internal master clock from an external LRCLK, the ADAU1962A can eliminate the need for a separate high frequency master clock and can be used with or without a bit clock. The DACs are designed using the latest Analog Devices continuous time architectures to further minimize EMI.

  • Page 20: Quad Analog-To-Digital Converter (Adau1979)

    FlexRay™. The BCM89810 is designed to exceed automotive specifications for noise cancellation and transmission jitter, providing consistent and reliable operation over the broadest range of single-pair twisted-pair automotive cable plants. The BCM89810 is based on Broadcom's proven 2–8 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com.

  • Page 21: Fractional-N Clock Multiplier (Cs2100)

    RGMII and MII interface specifications, allowing compatibility with industry-standard Ethernet media access controllers (MACs) and switch controllers. By default this transceiver is not supported on the board. Contact Analog Devices for more information on how to enable this interface.

  • Page 22: Usb To Uart (Ft232R)

    • True 5V/3.3V/2.8V/1.8V CMOS drive output and TTL input • Configurable I/O pin output drive strength • Integrated power-on-reset circuit • Fully-integrated AVCC supply filtering - no external filtering required. • UART signal inversion option 2–10 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 23: Triple Channel, High Measurement, Shunt And Bus Voltage Monitor (Ina3221)

    The expansion interface is architected to provide support for modularity with different expansion board types. These types fall into several categories including audio, video, converter, and asynchronous memory. More information about available extender boards can be found at: http://www.analog.com/en/design-center/land- ing-pages/001/sharc-processors-software-and-tools.html ® 2–11 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 24: Hardware Reference

    Hardware Reference 3 Hardware Reference This chapter describes the hardware design of the ADSP-SC573 EZ-KIT . System Architecture The board's configuration is shown in the Block Diagram figure. ® 3–1 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 25: Software-Controlled Switches (Softconfig)

    The remaining mechanical switches are provided for the boot mode and pushbuttons. Reference any file found in the installation directory for an example of how to set up the SoftConfig feature of SoftConfig*.c 3–2 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com.

  • Page 26: Overview Of Softconfig

    1 through software that EXAMPLE_SIGNAL_B ENABLE_A interfaces with the Microchip. The same procedure for disconnects from ENABLE_B EXAMPLE_SIGNAL_C EXAMPLE_SIGNAL_D Figure 3-2: Example of Individual FET Switches ® 3–3 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 27 In this example, the Microchip IO expander is not shown but controls the signal and allows the user to change the selection CONTROL_LETTER_NUMBER through software. 3–4 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 28 OFF. In order to connect the letters instead of the numbers, the user physically changes all switches on to the OFF position and all switches on to the ON position. ® 3–5 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 29: Softconfig On The Board

    S/PDIF RCA input and output connectors enabled Pushbuttons Enabled LEDs Enabled Programming SoftConfig Switches On the board, two Microchip MCP23017 devices exist. Each of these devices have the following programming characteristics: 3–6 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 30 ) is controlling the enable signal of a FET switch. Also note that if a particular functionality of the processor signal is being used, it is in bold font in the Processor Signal column. ® 3–7 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com.
  • Page 31 U15 and DAI0_PIN19, DAI0_PIN20 J1 and J10 SPDIF_ tors OPTICAL Enables S/PDIF digital connec- U16 and DAI0_PIN19, DAI0_PIN20 High SPDIF_ tors DIGITAL_EN 3–8 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 32 (if applicable) Enables ADAU1977 DAI0_PIN20, DAI0_PIN12, High ADAU1977_EN DAI0_PIN06 and DAI0_PIN07 Enables ADAU1977 FAULT and PD_01/GPIO/SMC0_D01 and High ADAU1977_ RESET PD_00/GPIO/SMC0_D00 FAULT_RST_EN ® 3–9 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 33: Switches

    ISOLATE SMC0_A09 NOT USED NOT USED Switches This section describes operation of the switches. The switch locations are shown in the Switch Locations figure. Figure 3-6: Switch Locations 3–10 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 34: Boot Mode Select ( Sw1 )

    The CAN Wake switch provides a high or low rising edge signal to the WAKE pin on each of the CAN transceivers. This will change the state of the transceiver from sleep to normal mode. ® 3–11 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com.

  • Page 35: Jtag Interface ( Sw6 And Sw7 )

    Table 3-10: Multiple Processor Configuration Location EZ-KIT connected to emualtor EZ-KIT not conencted to emulator SW6.1 SW6.2 SW6.3 SW6.4 SW6.5 SW6.6 SW7.1 SW7.2 SW7.3 SW7.4 3–12 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 36: Jumpers

    Table 3-11: CAN INH Jumper Installed Jumper Driver 1 and 2 TJA1055 2 and 3 TJA1145 ® 3–13 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 37: Regulator Disable ( Jp4 )

    3.3V 3 and 4 1.8V 5 and 6 VDD_INT 7 and 8 LEDs This section describes the on-board LEDs. The LED Locations figure shows the LED locations. 3–14 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 38: Fault ( Led1 )

    LED4-6 The BCM89810 status LEDs are used to indicate activity and the speed of the link that was established. Table 3-14: BCM89810 Status LEDs Status LED4 LED5 100M ® 3–15 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 39: A 2 B Interrupt ( Led8 )

    LED. For more information, see Reset Pushbutton ( DP83865 Status ( LED23-26 The DP83865status LEDs are used to indicate activity and the speed of the link that was established. 3–16 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 40: Connectors

    NOTE: Connectors on the back of the board are noted with dotted lines. S/PDIF Optical Tx ( Part Description Manufacturer Part Number Fiber optic transmitter Everlight PLT133/T10W Mating Cable Standard TOSLINK optical digital cable ® 3–17 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 41: Clock ( J2 )

    Ethernet 10/100 ( Part Description Manufacturer Part Number RJ45 Assmann A-2004-2-4-LPS-N-R Mating Cable Standard CAT 5e Etherent cable Link Port/JTAG ( J8 and J9 3–18 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 42: S/Pdif Optical Rx

    MLB ( Part Description Manufacturer Part Number 40-pin high speed socket Samtec QSH-020-01-L-D-DP-A Mating Connector 40-pin high speed header Samtec QTH-0202-01-L-D-DP-A Headphone ( ® 3–19 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.

  • Page 43: Hadc ( J15-J17 And J19 )

    TYCO (2-5767004-2). At this time, there are no trace pods available. USB to UART( Part Description Manufacturer Part Number USB Micro-AB Hirose ZX62D-AB-5P8 Mating Cable USB Micro-B to Standard-A cable 3–20 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 44 Part Description Manufacturer Part Number USB Micro-AB Hirose ZX62D-AB-5P8 Mating Cable USB Micro-B to Standard-A or Micro-A to Standard-A receptacle cable Power Terminal Block ( ® 3–21 ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 45 Expansion Interface 3 ( P1A, P1B and P1C Part Description Manufacturer Part Number 120-pin, 0.6 mm Hirose FX8-120P-SV1(91) Mating Connector 120-pin, 0.6 mm Hirose FX8-120S-SV(21) 3–22 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
  • Page 46 ® ADSP-SC573 EZ-KIT Manual Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
