3. Execute the desired PLL programming sequence.
mation, see "PLL Start-Up" on page
4. Wait 4096
PLL has settled to the new frequency.
5. Reprogram the SDRAM registers (
priate to the new
set.
6. Bring the SDRAM out of self-refresh mode by performing a
dummy read SDRAM access.
7. The SDC now issues the commands
ize the SDC and the SDRAM to the new frequency.
The SDRAM device is now ready to be accessed.

DDR2 Controller

The following sections are specific to DDR2 SDRAM memory on the
ADSP-2146x processor.

Power-Up Sequence

The following steps are used to power-up the DDR2 device.
1. Ensure the minimum DDR2 clock frequency is stable and at least
125 MHz (according to datasheet).
2. Program the core to DDR2 clock ratio using the
PLL changes wait at least 4096 core cycles, for output divider
changes at least 15 core clock cycles for effect latency.
3. If a new frequency is desired, put the on-chip DLL into reset using
DLL1-0CTL1
4. Wait at least 9 core cycles for the DLL to lock to a new frequency.
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
cycles (
CLKIN
RESETOUT
frequency and assure that the
SDCLK
registers.
External Port
(For more infor-
22-9.)
asserted) which indicates the
,
) with values appro-
SDRRC
SDCTL
,
and
PREA
8xREF
PMCTL
bit is
SDPSS
to initial-
MRS
register. For
3-129
