Peripheral Registers
31 30
15
IIR_DMAURCHNL (11–7)
Current Channel
IIR_DMAACDONE
All Channels Done
IIR_DMAWDONE
Processing of Current Channel Done
IIR_DMASVDK
Saving Updated Dk State in Internal
Memory
Figure A-43. IIRDMASTAT Register
Table A-55. IIRDMASTAT Register Bit Descriptions (RO)
Bits Name
0 IIR_DMACPL
1 IIR_DMACnDkLD
2 IIR_DMAPPGS
3 IIR_DMAWRBK
4 IIR_DMASVDk
5 (ROC) IIR_DMAWDONE
6 (ROC) IIR_DMAACDONE
11–7 IIR_DMACURCHNL
31–12 Reserved
