Peripherals Routed Through the DAI
Table A-85. SPCTLx Register Bit Descriptions (I
Left-Justified) (RW) (Cont'd)
Bit Name
18 SDEN_A
19 SCHEN_A
20 SDEN_B
21 SCHEN_B
22 Reserved
23 BHD
24 SPEN_B
25 SPTRAN
A-160
www.BDTIC.com/ADI
Description
Enable Channel A Serial Port DMA.
0 = Disable serial port channel A DMA
1 = Enable serial port channel A DMA
Enable Channel A Serial Port DMA Chaining.
0 = Disable serial port channel A DMA chaining
1 = Enable serial port channel A DMA chaining
Enable Channel B Serial Port DMA.
0 = Disable serial port channel B DMA
1 = Enable serial port channel B DMA
Enable Channel B Serial Port DMA Chaining.
0 = Disable serial port channel B DMA chaining
1 = Enable serial port channel B DMA chaining
Buffer Hang Disable.
0 = Indicates a core stall. The core stalls when it tries to write to a full
transmit buffer or read an empty receive buffer FIFO.
1 = Ignore a core hang
Enable Channel B Serial Port.
0 = Serial port A channel disabled
1 = Serial port A channel enabled
Data Direction Control. This bit controls the data direction of the
serial port channel A and B signals.
When cleared (= 0) the SPORT is configured to receive on both chan-
nels A and B. When configured to receive, the RXSPxA and RXSPxB
buffers are activated, while the receive shift registers are controlled by
SPORTx_CLK and SPORTx_FS. The TXSPxA and TXSPxB buffers
are inactive.
When set (= 1) the SPORT is configured to transmit on both channels
A and B. When configured to transmit, the TXSPxA and TXSPxB buf-
fers are activated, while the transmit shift registers are controlled by
SPORTx_CLK and SPORTx_FS. The RXSPxA and RXSPxB buffers
are inactive.
