DAI Signal Routing Unit Registers
Table A-79. Group E Sources – Miscellaneous Signals (Cont'd)
Selection Code
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
10011 (0x13)
10100 (0x14)
10101 (0x15)
10110 (0x16)
10111 (0x17)
11000 (0x18)
11001 (0x19)
11010 (0x1A)
11011 (0x1B)
11100 (0x1C)
11101 (0x1D)
11110 (0x1E)
11111 (0x1F)
A-140
www.BDTIC.com/ADI
Source Signal
DAI_PB16_O
DAI_PB17_O
DAI_PB18_O
DAI_PB19_O
DAI_PB20_O
SPORT0_FS_O
SPORT1_FS_O
SPORT2_FS_O
SPORT3_FS_O
SPORT4_FS_O
SPORT5_FS_O
DIT_BLKSTART_O
PCG_FSA_O
PCG_CLKB_O
PCG_FSB_O
LOW
HIGH
ADSP-214xx SHARC Processor Hardware Reference
Description (Output Source Selection)
Pin Buffer 16 Output
Pin Buffer 17 Output
Pin Buffer 18 Output
Pin Buffer 19 Output
Pin Buffer 20 Output
SPORT0 Frame Sync
SPORT1 Frame Sync
SPORT2 Frame Sync
SPORT3 Frame Sync
SPORT4 Frame Sync
SPORT5 Frame Sync
S/PDIF TX Block Start Output
Precision Frame Sync A
Precision Clock B
Precision Frame Sync B
Logic Level Low (0) as a Source
Logic Level High (1) as a Source
