Table A-11. DDR2CTL0 Register Bit Descriptions (RW) (Cont'd)
Bit Name
11–9 DDR2RAW
12 (WO) FEMR2
13 (WO) FDLLCAL
14 DDR2ADDRMODE Select the Address Mapping. This bit selects how the data are
15 (WO) DDR2PSS
16 DDR2WDTHx16
17 (WO) FEMR3
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Description
Row Address Width.
000 = 8 bits
001 = 9 bits
...
111 = 15 bits
Force EMR2 Register Write. Forces EMR2 only if the banks
are all precharged.
0 = No effect
1 = Force EMR2 register write to DDR2
Force DLL External Bank Calibration. Triggers a DLL calibra-
tion sequence to all of the external banks assigned to DDR2
controller in the EPCTL register (BxSD bits). Note for each
bank the calibration takes 300 DDR2 cycles.
0 = No effect
1 = Trigger DLL for external bank calibration
stored in the DDR2 memory.
0 = Page interleaving map (consecutive pages/different banks)
1 = Bank interleaving map (consecutive banks)
Power-Up Sequence Start. The power-up sequence is started
by setting this bit. Note that the entire power-up sequence
takes many cycles to complete. The more external banks
assigned, the longer the power-up time.
0 = No effect
1 = Trigger power-up sequence
Note that the power-up sequence does NOT require a user
access to be executed.
External Data Path Width. Programs should always set (=1)
this bit.
0 = Reserved
1 = 16-bit
Force EMR3 Register Write. Forces EMR3 only if the banks
are all precharged.
0 = No effect
1 = Force EMR3 register write to DDR2
Registers Reference
