Programming Model
2. Initialize the period register with the value of the maximum exter-
nal count.
3. Set the
TIMEN
starts the count down.
When the period expires, it is reloaded with the period value and
the cycle repeats. Counter counts with each edge of the input wave-
form, asynchronous to
When the period expires,
asserted. An external clock can trigger the Timer to issue an inter-
rupt and wake up an idle processor.
Reads of the count register are not supported in EXT_CLK mode.
