equally by all 31 channels with four words for each channel. The buffer
depth can be up to 124 words (quadlets), when only one channel is used.
Table A-71. MLB_LCBCRx Register Description (RW)
Bit Name
12–0 SA
21–13 BD
31–22 TH
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Description
Buffer Start Address. Determines the starting address (in
quadlets/4) of the channel buffer for the logical channel x.
Reset value = {120, 116, 112 ...4, 0} for x = 30:0
0x0000 = start address offset of 0 words
0x0001 = start address offset of 4 words
0x0002 = start address offset of 8 words
...
0x001E = start address offset of 120 words
0x001F to 0x1FFF = Reserved
Buffer Depth. Defines the depth (in quadlets/4–1) of the local
channel buffer for the logical channel x.
0x000 = depth = 4 words
0x001 = depth = 8 words
0x002 = depth = 12 words
...
0x01E = depth = 124 words
0x01F to 0x1FF = Reserved
Reset value = 4 for all x=0:30
Buffer Threshold. Defines the threshold (in quadlets/2) of the
local channel buffer for the logical channel x in I/O mode.
Hardware uses this threshold value to determine when to issue
an I/O service request to system software.
Reset value = 2 for all x = 0:30
0x000 = threshold = 0 word
0x001 = threshold = 2 words
0x002 = threshold = 4 words
....
0x03D = threshold = 122 words
0x03E to 0x3FF = Reserved
Reserved in DMA mode
