Pin Descriptions
The timer has only one pin which acts as input or output based on the
timer mode as shown in
Table 16-2. Peripheral Timer Pin Descriptions
Internal Node
TIMER1–0_I
TIMER1–0_O
TIMER1–0_PBEN_O
SRU Programming
Since the timer has operation modes for input (capture and external clock
mode) and output (PWM out mode), it requires bidirectional junctions.
Table 16-3 shows the required SRU routing.
Table 16-3. Timer DPI/SRU2 Signal Connections
Internal Node
Inputs
TIMER1–0_I
Outputs
TIMER1–0_O
TIMER1–0_PBEN_O
See also "DPI Routing Capabilities" on page
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Table 16-2.
Type Description
I Timer Signal. This input is active sampled during pulse
width and period capture (width capture mode) or external
event watchdog (external clock mode).
O Timer Signal. This output is active driven in pulse width
modulation (PWM out mode).
O Timer Pin Buffer Enable Output Signal. This output is only
driven in PWM out mode.
DPI Group
Group A
Group B
Group C
Peripheral Timers
SRU Register
SRU_INPUT2
9-25.
