ADSP-2146x External Port Registers
Table A-11. DDR2CTL0 Register Bit Descriptions (RW) (Cont'd)
Bit
Name
18 (WO) DDR2SRF
19
DDR2ORF
20 (WO) FARF
21 (WO) FPC
22 (WO) FLMR
23 (WO) FEMR
24
DDR2BUF
25 (WO) SREF_EXIT
A-28
www.BDTIC.com/ADI
Description
Self-Refresh Mode.
0 = No effect
1 = Enters sel-refresh mode
Auto-Refresh Command. If this bit is set, the auto-refresh
command is not issue to the DDR2 memory. This mode allows
data streaming connection to FPGA were the refresh is not
required.
0 = Auto-refresh command occurs when refresh counter
expires.
1 = Auto-refresh not performed
Force Auto-Refresh. This bit allows programs to explicitly trig-
ger an auto-refresh command. To use this bit requires that bit
21 is also set, otherwise the DDR2 may crash.
0 = No effect
1 = Force auto-refresh
Force Precharge All. This bit allows programs to explicitly trig-
ger a PREA command.
0 = No effect
1 = Force precharge
Force Load Mode Register. Forces MR only if the banks are all
precharged.
0 = No effect
1 = Force MR register write to DDR2
Force EMR Register Write. Forces EMR only if the banks are
all precharged.
0 = No effect
1 = Force EMR register write to DDR2
Enable Pipeline. Enabled this bit if the nominal capacitive
load is exceeded by connecting DDR2 chips in parallel
(4 x IO4).
0 = Disable
1 = External DDR2 control/address buffer enable
Self-Refresh Exit.
ADSP-214xx SHARC Processor Hardware Reference
