Table A-77. Group C Sources – Frame Sync
Selection Code
00000 (0x0)
00001 (0x1)
00010 (0x2)
00011 (0x3)
00100 (0x4)
00101 (0x5)
00110 (0x6)
00111 (0x7)
01000 (0x8)
01001 (0x9)
01010 (0xA)
01011 (0xB)
01100 (0xC)
01101 (0xD)
01110 (0xE)
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
10011 (0x13)
10100 (0x14)
10101 (0x15)
10110 (0x16)
10111 (0x17)
11000 (0x18)
11001 (0x19)
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Source Signal
DAI_PB01_O
DAI_PB02_O
DAI_PB03_O
DAI_PB04_O
DAI_PB05_O
DAI_PB06_O
DAI_PB07_O
DAI_PB08_O
DAI_PB09_O
DAI_PB10_O
DAI_PB11_O
DAI_PB12_O
DAI_PB13_O
DAI_PB14_O
DAI_PB15_O
DAI_PB16_O
DAI_PB17_O
DAI_PB18_O
DAI_PB19_O
DAI_PB20_O
SPORT0_FS_O
SPORT1_FS_O
SPORT2_FS_O
SPORT3_FS_O
SPORT4_FS_O
SPORT5_FS_O
Registers Reference
Description (Source Selection)
Pin Buffer 1
Pin Buffer 2
Pin Buffer 3
Pin Buffer 4
Pin Buffer 5
Pin Buffer 6
Pin Buffer 7
Pin Buffer 8
Pin Buffer 9
Pin Buffer 10
Pin Buffer 11
Pin Buffer 12
Pin Buffer 13
Pin Buffer 14
Pin Buffer 15
Pin Buffer 16
Pin Buffer 17
Pin Buffer 18
Pin Buffer 19
Pin Buffer 20
SPORT 0 Frame Sync
SPORT 1 Frame Sync
SPORT 2 Frame Sync
SPORT 3 Frame Sync
SPORT 4 Frame Sync
SPORT 5 Frame Sync
