Table 15-3. SPI DPI/SRU2 Signal Connections
Internal Node
Inputs
SPI_CLK_I
SPIB_CLK_I
SPI_DS_I
SPIB_DS_I
SPI_MOSI_I
SPIB_MOSI_I
SPI_MISO_I
SPIB_MISO_I
Outputs
SPI_CLK_O
SPIB_CLK_O
SPI_MOSI_O
SPIB_MOSI_O
SPI_MISO_O
SPIB_MISO_O
SPI_FLG3–0_O
SPIB_FLG3–0_O
SPI_CLK_PBEN_O
SPIB_CLK_PBEN_O
SPI_MOSI_PBEN_O
SPIB_MOSI_PBEN_O
SPI_MISO_PBEN_O
SPIB_MISO_PBEN_O
SPI_FLG3–0_PBEN_O
SPIB_FLG3–0_PBEN_O
Register Overview
This section provides brief descriptions of the major registers. For com-
plete information see
page A-232.
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Serial Peripheral Interface Ports
DPI Group
Group A
Group B
Group C
"Serial Peripheral Interface Registers" on
SRU2 Register
SRU2_INPUT1–0
15-5
