Peripheral Registers
Table A-34. LSTATx Register Bit Descriptions (RO)
Bit
Name
0 (ROC)
LTRQ
1 (ROC)
LRRQ
2 (ROC)
DMACH_IRPT
3 (ROC)
LPIT
4 (ROC)
EXTTXFR_DONE
6–5
FFST
7
LERR
8
LPBS
31–9
Reserved
Memory-to-Memory Registers
The following DMA related registers are used when performing inter-
nal-to-internal DMA through the MTM port.
DMA Control (MTMCTL Register)
The
register
MTMCTL
64-bit data from one internal memory location to another.
A-66
www.BDTIC.com/ADI
Description
Link Port Transmit Request Status.
Link Port Receive Request Status.
DMA Channel Count Interrupt.
Link Port Invalid Transmit Interrupt.
External Transfer Done Interrupt.
Link Buffer Status.
00 = empty, 01 = reserved, 10 = one word, 11 = full
(Cleared when the Link Port is disabled)
Link Buffer Receive Pack Error Status.
0 = Packing complete
1 = Packing incomplete
Link Port Bus Status (Transmitter). To safely disable
linkport transmit operation first poll the FFST bit and
second the LPBS bit.
0 = Bus is idle
1 = Bus busy
(Figure
A-30) allows programs to transfer blocks of
