Table A-4. PMCTL1 Register Bit Descriptions (RW) (Cont'd)
Bit Name
4 DAIOFF
5 EPOFF
6 SP01OFF
7 SP23OFF
8 SP45OFF
9 SP67OFF
10 SP1OFF
11 TMROFF
12 LP0OFF
13 LP1OFF
15–14 Reserved
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Description
Shutdown Clock to DAI. Shutdown clock to DAI related
peripherals—SRU, SRC, S/PDIF, PCG, IDP, PDAP
0 = DAI is in normal mode
1 = Shutdown clock to DAI
Shutdown Clock to External Port.
0 = External port is in normal mode
1 = Shutdown clock to external port
Shutdown Clock to SPORT 0, 1.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
Shutdown Clock to SPORT 2, 3.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
Shutdown Clock to SPORT 4, 5.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
Shutdown Clock to SPORT 6, 7.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
Shutdown Clock to SPI/SPIB.
0 = SPI in normal mode
1 = Shutdown clock to SPI
Shutdown Clock to Peripheral Timer.
0 = Timer is in normal mode
1 = Shutdown clock to timer
Shutdown Clock to Link Port 0.
0 = LP0 is in normal mode
1 = Shutdown clock to LP0
Shutdown Clock to Link Port 1.
0 = LP1 is in normal mode
1 = Shutdown clock to LP1
