Table A-84. SPCTLx Register Bit Descriptions (Standard Serial Mode)
(RW) (Cont'd)
Bit
Name
12
CKRE
13
FSR
14
IFS
15
DIFS
16
LFS
17
LAFS
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Description
Clock Rising Edge Select. Determines clock signal to sample data and
the frame sync selection. For sampling receive data and frame syncs, set-
ting CKRE to 1 selects the rising edge of SPORTx_CLK. When CKRE
is cleared (=0), the processor selects the falling edge of SPORTx_CLK
for sampling receive data and frame syncs. Note that transmit data and
frame sync signals change their state on the clock edge that is not
selected.
For example, the transmit and receive functions of any two SPORTs
connected together should always select the same value for CKRE so
internally- generated signals are driven on one edge and received signals
are sampled on the opposite edge.
0 = Falling edge
1 = Rising edge
Frame Sync Required Select. Selects whether the serial port requires (if
set, = 1) or does not require a transfer frame sync (if cleared, = 0).
Internal Frame Sync Select. Selects whether the serial port uses an
internally generated frame sync (if set, = 1) or uses an external frame
sync (if cleared, = 0).
Data Independent Frame Sync Select.
1 = Serial port uses a data-independent frame sync (sync at selected
interval)
0 = Serial port uses a data-dependent frame sync (sync when TX FIFO
is not empty or when RX FIFO is not full).
Active Low Frame Sync Select. This bit selects the logic level of the
(transmit or receive) frame sync signals. This bit selects an active low
frame sync (if set, = 1) or active high frame sync (if cleared, = 0).
Late Transmit Frame Sync Select. This bit selects when to generate the
frame sync signal. This bit selects a late frame sync if set (= 1) during
the first bit of each data word. This bit selects an early frame sync if
cleared (= 0) during the serial clock cycle immediately preceding the
first data bit
0 = Early frame sync (FS before first bit)
1 = Late frame sync (FS during first bit)
Registers Reference
A-155
