Register Listing
Register Mnemonic
CPSPIB
SPIDMACB
Timer Registers
TM0STAT
TM0CTL
TM0CNT
TM0PRD
TM0W
TM1STAT
TM1CTL
TM1CNT
TM1PRD
TM1W
SRU DAI Routing Registers
SRU_CLK0
SRU_CLK1
SRU_CLK2
SRU_CLK3
SRU_CLK4
SRU_CLK5
SRU_DAT0
SRU_DAT1
SRU_DAT2
SRU_DAT3
SRU_DAT4
SRU_DAT5
SRU_DAT6
A-284
www.BDTIC.com/ADI
Address Description
0x2883 Points to Next DMA Parameters
0x2884 SPIB DMA Control
0x1400 GP Timer 0 Status
0x1401 GP Timer 0 Control
0x1402 GP Timer 0 Count
0x1403 GP Timer 0 Period
0x1404 GP Timer 0 Width
0x1408 GP Timer 1 Status
0x1409 GP Timer 1 Control
0x140A GP Timer 1 Count
0x140B GP Timer 1 Period
0x140C GP Timer 1 Width
0x2430 SRU Clock Control 0
0x2431 SRU Clock Control 1
0x2432 SRU Clock Control 2
0x2433 SRU Clock Control 3
0x2434 SRU Clock Control 4
0x2435 SRU Clock Control 5
0x2440 SRU Data Control 0
0x2441 SRU Data Control 1
0x2442 SRU Data Control 2
0x2443 SRU Data Control 3
0x2444 SRU Data Control 4
0x2445 SRU Data Control 5
0x2446 SRU Data Control 6
ADSP-214xx SHARC Processor Hardware Reference
Reset
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x2526 30C2
0x3DEF 7BDE
0x3DEF 7BDE
0x3DEF 7BDE
0x3DEF 7BDE
0x3DEF 7BDE
0x0814 4040
0x0F38 B289
0x0000 0450
0x0
0x0
0x0
0x00FB EFBE
