Figure A-95. IDP_CTL2 Register
Table A-92. IDP_CTL2 Register Bit Descriptions (RW)
Bit Name
7–0 FAEx
8–31 Reserved
Parallel Data Acquisition Port Control Register
(IDP_PP_CTL)
The
IDP_PP_CTL
Table A-93) provides 20 mask bits that allow the input from any of the 20
pins to be ignored.
For more information on the operation of the parallel data acquisition
port, see Chapter 11, Input Data
ing that is used in conjunction with this module, see
on page 23-28.
