DPI Signal Routing Unit Registers
Table A-117. SR_CTL Register Bit Descriptions (RW)
Bit Name
0 SR_LDOE
1 SR_SW_CLR
6–2 SR_SDO_SEL
31–7 Reserved
DPI Signal Routing Unit Registers
The digital peripheral interface is comprised of a group of peripherals and
the signal routing unit 2 (SRU2).
Miscellaneous Signal Routing Registers
(SRU2_INPUTx, Group A)
Group A is used to route the 14 external pin signals to the inputs of the
other peripherals. The
or the pin buffer enable signals (
All clock inputs that are not used should be set to logic low. The registers
and input signals for group A are summarized in
Figure A-123 and
A-218
www.BDTIC.com/ADI
Description
Parallel Data Output Enable. This bit enables the parallel
SR_LD017–0 output pins. It is cleared on chip reset (RESET)
and/or asynchronously on external SR_CLR pin.
Software Clear/Reset. If this bit is 0, then the reset is active.
0 = Shift register cleared
1 = Shift register enabled
Serial Data Out Multiplexer's Select Input. These bits select
which parallel word is shifted through the SR_SDO pin.
00000 = LSB selected.
10001 = MSB selected.
outputs route to the interrupt latch bits
MISCBx_O
).
PBEN
Table A-118.
ADSP-214xx SHARC Processor Hardware Reference
Figure A-118 through
