Peripherals Routed Through the DAI
Table A-95. DAI_STAT1 Register Bit Descriptions (RO) (Cont'd)
Bit Name
7–4 FIFO_RDI
31–8 Reserved
Sample Rate Converter Registers
The sample rate converter (SRC) is composed of five registers which are
described in the following sections.
Control Registers (SRCCTLx)
The control registers (read/write) control the operating modes,
SRCCTLn
filters, and data formats used in the sample rate converter. For n = 0, the
register controls the SRC0 and SRC1 modules and for n = 1 it controls the
SRC2 and SRC3 modules (x = 0, 2 and y = 1, 3). The bit settings for these
registers are shown in
A-184
www.BDTIC.com/ADI
Description
Read Index Pointer. Reflects the read index status during
core reads from the IDP_FIFO.
0000 = No read done
1000 = 8 reads done
Figure A-98 and described in
ADSP-214xx SHARC Processor Hardware Reference
Table A-96.
