Register Listing
Register Mnemonic
IDP_DMA_M0
IDP_DMA_M1
IDP_DMA_M2
IDP_DMA_M3
IDP_DMA_M4
IDP_DMA_M5
IDP_DMA_M6
IDP_DMA_M7
IDP_DMA_C0
IDP_DMA_C1
IDP_DMA_C2
IDP_DMA_C3
IDP_DMA_C4
IDP_DMA_C5
IDP_DMA_C6
IDP_DMA_C7
IDP_DMA_PC0
IDP_DMA_PC1
IDP_DMA_PC2
IDP_DMA_PC3
IDP_DMA_PC4
IDP_DMA_PC5
IDP_DMA_PC6
IDP_DMA_PC7
Precision Clock Generator Registers
PCG_CTLA0
PCG_CTLA1
A-288
www.BDTIC.com/ADI
Address Description
0x2410 IDP DMA Channel 0 Modify
0x2411 IDP DMA Channel 1 Modify
0x2412 IDP DMA Channel 2 Modify
0x2413 IDP DMA Channel 3 Modify
0x2414 IDP DMA Channel 4 Modify
0x2415 IDP DMA Channel 5 Modify
0x2416 IDP DMA Channel 6 Modify
0x2417 IDP DMA Channel 7 Modify
0x2420 IDP DMA Channel 0 Count
0x2421 IDP DMA Channel 1 Count
0x2422 IDP DMA Channel 2 Count
0x2423 IDP DMA Channel 3 Count
0x2424 IDP DMA Channel 4 Count
0x2425 IDP DMA Channel 5 Count
0x2426 IDP DMA Channel 6 Count
0x2427 IDP DMA Channel 7 Count
0x2428 IDP DMA Channel 0 Ping Pong Count
0x2429 IDP DMA Channel 1 Ping Pong Count
0x242A IDP DMA Channel 2 Ping Pong Count
0x242B IDP DMA Channel 3 Ping Pong Count
0x242C IDP DMA Channel 4 Ping Pong Count
0x242D IDP DMA Channel 5 Ping Pong Count
0x242E IDP DMA Channel 6 Ping Pong Count
0x242F IDP DMA Channel 7 Ping Pong Count
0x24C0 Precision Clock A Control 0
0x24C1 Precision Clock A Control 1
ADSP-214xx SHARC Processor Hardware Reference
Reset
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
