Analog Devices SHARC ADSP-214 Series Hardware Reference Manual page 1115

Register Mnemonic
PCG_CTLB0
PCG_CTLB1
PCG_CTLC0
PCG_CTLC1
PCG_CTLD0
PCG_CTLD1
PCG_PW1
PCG_PW2
PCG_SYNC1
PCG_SYNC2
Programmable Interrupt Priority Control Registers
PICR0
PICR1
PICR2
PICR3
Pulse Width Modulation Registers
PWMGCTL
PWMGSTAT
PWMCTL0
PWMSTAT0
PWMPERIOD0
PWMDT0
PWMA0
PWMB0
PWMSEG0
PWMAL0
PWMBL0
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Address Description
0x24C2 Precision Clock B Control 0
0x24C3 Precision Clock B Control 1
0x24C6 Precision Clock C Control 0
0x24C7 Precision Clock C Control 1
0x24C8 Precision Clock D Control 0
0x24C9 Precision Clock D Control 1
0x24C4 Precision Clock Pulse Width Control 1
0x24CA Precision Clock Pulse Width Control 2
0x24C5 Precision Clock Frame Sync Synchronization 1
0x24CB Precision Clock Frame Sync Synchronization 2
0x2200 Programmable Interrupt Priority Control 0
0x2201 Programmable Interrupt Priority Control 1
0x2202 Programmable Interrupt Priority Control 2
0x2203 Programmable Interrupt Priority Control 3
0x3800 PWM Global Control
0x3801 PWM Global Status
0x3000 PWM Control 0
0x3001 PWM Status 0
0x3002 PWM Period 0
0x3003 PWM Dead Time 0
0x3005 PWM Channel A Duty Control 0
0x3006 PWM Channel B Duty Control 0
0x3008 PWM Output Enable 0
0x300A PWM Channel AL Duty Control 0
0x300B PWM Channel BL Duty Control 0
Registers Reference
Reset
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0
0x0A41 8820
0x16A4 A0E6
0x2307 B9AC
0x0000 0012
0x0
0x0
0x0
0x0009
0x0
0x0
0x0
0x0
0x0
0x0
0x0
A-289
