Peripherals Routed Through the DPI
15 14
TWIRXINT
Receive FIFO Service
TWITXINT
Transmit FIFO Service
TWIMERR
Master Transfer Error
TWIMCOM
Master Transfer Complete
Figure A-153. TWIIRPTL Register
Table A-144. TWIIRPTL Register Bit Descriptions (W1X)
Bit Name
0 TWISINIT
1 TWISCOMP
2 TWISERR
3 TWISOVF
4 TWIMCOM
A-266
www.BDTIC.com/ADI
13 12 11 10 9 8 7 6
Description
Slave Transfer Initiated.
0 = A transfer is not in progress. An address match has not occurred
since the last time this bit was cleared.
1 = The slave has detected an address match and a transfer has been
initiated.
Slave Transfer Complete.
0 = The completion of a transfer not detected
1 = The transfer is complete and either a stop, or a restart was
detected.
Slave Transfer Error.
0 = No errors detected
1 = An error has occurred. A restart or stop condition has occurred
during the data receive phase of a transfer.
Slave Overflow.
0 = No overflow detected
1 = The slave transfer complete (TWISCOMP) was set at the time a
subsequent transfer has acknowledged an address phase. The transfer
continues, however, it may be difficult to delineate data of one trans-
fer from another.
Master Transfer Complete.
0 = The completion of a transfer not detected
1 = The initiated master transfer is complete. In the absence of a
repeat start, the bus is released.
ADSP-214xx SHARC Processor Hardware Reference
5 4 3 2 1 0
TWISINIT
Slave Transfer Initiated
TWISCOMP
Slave Transfer Complete
TWISERR
Slave Transfer Error
TWISOVF
Slave Overflow
