Register Mnemonic
MLB_LCBCR1
MLB_CECR2
MLB_CSCR2
MLB_CCBCR2
MLB_CNBCR2
MLB_LCBCR2
MLB_CECR3
MLB_CSCR3
MLB_CCBCR3
MLB_CNBCR3
MLB_LCBCR3
MLB_CECR4
MLB_CSCR4
MLB_CCBCR4
MLB_CNBCR4
MLB_LCBCR4
MLB_CECR5
MLB_CSCR5
MLB_CCBCR5
MLB_CNBCR5
MLB_LCBCR5
MLB_CECR6
MLB_CSCR6
MLB_CCBCR6
MLB_CNBCR6
MLB_LCBCR6
MLB_CECR7
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Address Description
0x41A1 Channel 1 Local Channel Buffer Control
0x4118 Channel 2 Control
0x4119 Channel 2 Status
0x411A Channel 2 Current Buffer (RX Buffer in I/O Mode)
0x411B Channel 2 Next Buffer (TX Buffer in I/O Mode)
0x41A2 Channel 2 Local Channel Buffer Control
0x411C Channel 3 Control
0x411D Channel 3 Status
0x411E Channel 3 Current Buffer (RX Buffer in I/O Mode)
0x411F Channel 3 Next Buffer (TX Buffer in I/O Mode)
0x41A3 Channel 3 Local Channel Buffer Control
0x4120 Channel 4 Control
0x4121 Channel 4 Status
0x4122 Channel 4 Current Buffer (RX Buffer in I/O Mode)
0x4123 Channel 4 Next Buffer (TX Buffer in I/O Mode)
0x41A4 Channel 4 Local Channel Buffer Control
0x4124 Channel 5 Control
0x4125 Channel 5 Status
0x4126 Channel 5 Current Buffer (RX Buffer in I/O Mode)
0x4127 Channel 5 Next Buffer (TX Buffer in I/O Mode)
0x41A5 Channel 5 Local Channel Buffer Control
0x4128 Channel 6 Control
0x4129 Channel 6 Status
0x412A Channel 6 Current Buffer (RX Buffer in I/O Mode)
0x412B Channel 6 Next Buffer (TX Buffer in I/O Mode)
0x41A6 Channel 6 Local Channel Buffer Control
0x412C Channel 7 Control
Registers Reference
Reset
0x0040 0001
0x0
0x8000 0000
0x0
0x0
0x0040 0002
0x0
0x8000 0000
0x0
0x0
0x0040 0003
0x0
0x8000 0000
0x0
0x0
0x0040 0004
0x0
0x8000 0000
0x0
0x0
0x0040 0005
0x0
0x8000 0000
0x0
0x0
0x0040 0006
0x0
A-299
