Register Mnemonic
MLB_CCBCR23
MLB_CNBCR23
MLB_LCBCR23
MLB_CECR24
MLB_CSCR24
MLB_CCBCR24
MLB_CNBCR24
MLB_LCBCR24
MLB_CECR25
MLB_CSCR25
MLB_CCBCR25
MLB_CNBCR25
MLB_LCBCR25
MLB_CECR26
MLB_CSCR26
MLB_CCBCR26
MLB_CNBCR26
MLB_LCBCR26
MLB_CECR27
MLB_CSCR27
MLB_CCBCR27
MLB_CNBCR27
MLB_LCBCR27
MLB_CECR28
MLB_CSCR28
MLB_CCBCR28
MLB_CNBCR28
ADSP-214xx SHARC Processor Hardware Reference
www.BDTIC.com/ADI
Address Description
0x416E Channel 23 Current Buffer (RX Buffer in I/O Mode) 0x0
0x416F Channel 23 Next Buffer (TX Buffer in I/O Mode)
0x41B7 Channel 23 Local Channel Buffer Control
0x4170 Channel 24 Control
0x4171 Channel 24 Status
0x4172 Channel 24 Current Buffer (RX Buffer in I/O Mode) 0x0
0x4173 Channel 24 Next Buffer (TX Buffer in I/O Mode)
0x41B8 Channel 24 Local Channel Buffer Control
0x4174 Channel 25 Control
0x4175 Channel 25 Status
0x4176 Channel 25 Current Buffer (RX Buffer in I/O Mode) 0x0
0x4177 Channel 25 Next Buffer (TX Buffer in I/O Mode)
0x41B9 Channel 25 Local Channel Buffer Control
0x4178 Channel 26 Control
0x4179 Channel 26 Status
0x417A Channel 26 Current Buffer (RX Buffer in I/O Mode) 0x0
0x417B Channel 26 Next Buffer (TX Buffer in I/O Mode)
0x41BA Channel 26 Local Channel Buffer Control
0x417C Channel 27 Control
0x417D Channel 27 Status
0x417E Channel 27 Current Buffer (RX Buffer in I/O Mode) 0x0
0x417F Channel 27 Next Buffer (TX Buffer in I/O Mode)
0x41BB Channel 27 Local Channel Buffer Control
0x4180 Channel 28 Control
0x4181 Channel 28 Status
0x4182 Channel 28 Current Buffer (RX Buffer in I/O Mode) 0x0
0x4183 Channel 28 Next Buffer (TX Buffer in I/O Mode)
Registers Reference
Reset
0x0
0x0040 0017
0x0
0x8000 0000
0x0
0x0040 0018
0x0
0x8000 0000
0x0
0x0040 0019
0x0
0x8000 0000
0x0
0x0040 001A
0x0
0x8000 0000
0x0
0x0040 001B
0x0
0x8000 0000
0x0
A-303
