Register Listing
Register Mnemonic
MLB_CECR18
MLB_CSCR18
MLB_CCBCR18
MLB_CNBCR18
MLB_LCBCR18
MLB_CECR19
MLB_CSCR19
MLB_CCBCR19
MLB_CNBCR19
MLB_LCBCR19
MLB_CECR20
MLB_CSCR20
MLB_CCBCR20
MLB_CNBCR20
MLB_LCBCR20
MLB_CECR21
MLB_CSCR21
MLB_CCBCR21
MLB_CNBCR21
MLB_LCBCR21
MLB_CECR22
MLB_CSCR22
MLB_CCBCR22
MLB_CNBCR22
MLB_LCBCR22
MLB_CECR23
MLB_CSCR23
A-302
www.BDTIC.com/ADI
Address Description
0x4158 Channel 18 Control
0x4159 Channel 18 Status
0x415A Channel 18 Current Buffer (RX Buffer in I/O Mode) 0x0
0x415B Channel 18 Next Buffer (TX Buffer in I/O Mode)
0x41B2 Channel 18 Local Channel Buffer Control
0x415C Channel 19 Control
0x415D Channel 19 Status
0x415E Channel 19 Current Buffer (RX Buffer in I/O Mode) 0x0
0x415F Channel 19 Next Buffer (TX Buffer in I/O Mode)
0x41B3 Channel 19 Local Channel Buffer Control
0x4160 Channel 20 Control
0x4161 Channel 20 Status
0x4162 Channel 20 Current Buffer (RX Buffer in I/O Mode) 0x0
0x4163 Channel 20 Next Buffer (TX Buffer in I/O Mode)
0x41B4 Channel 20 Local Channel Buffer Control
0x4164 Channel 21 Control
0x4165 Channel 21 Status
0x4166 Channel 21 Current Buffer (RX Buffer in I/O Mode) 0x0
0x4167 Channel 21 Next Buffer (TX Buffer in I/O Mode)
0x41B5 Channel 21 Local Channel Buffer Control
0x4168 Channel 22 Control
0x4169 Channel 22 Status
0x416A Channel 22 Current Buffer (RX Buffer in I/O Mode) 0x0
0x416B Channel 22 Next Buffer (TX Buffer in I/O Mode)
0x41B6 Channel 22 Local Channel Buffer Control
0x416C Channel 23 Control
0x416D Channel 23 Status
ADSP-214xx SHARC Processor Hardware Reference
Reset
0x0
0x8000 0000
0x0
0x0040 0012
0x0
0x8000 0000
0x0
0x0040 0013
0x0
0x8000 0000
0x0
0x0040 0014
0x0
0x8000 0000
0x0
0x0040 0015
0x0
0x8000 0000
0x0
0x0040 0016
0x0
0x8000 0000
