ADTRAN AOS Version R10.1.0 Command Reference Manual page 653

Command Reference Guide
Command History
Release 8.1
Release 10.1
Release 17.1
Release 17.2
Release A4.01
Release A5.01
Functional Notes
Use the realtime argument for this command to display full-screen output in real time. Information is
continuously updated on the console until you either freeze the data (by pressing the F key) or exit
realtime mode (by pressing Ctrl-C). If there is not enough room on the screen for all available data, the
information will truncate at the bottom of the screen. In order to maximize the amount of data displayed,
increase the terminal length (using the terminal length command; refer to
page 837).
Usage Examples
The following example shows detailed information about a device's neighbors:
>enable
#show lldp neighbors interface eth 0/3 detail
Chassis ID: 00:A0:C8:02:DD:2A (MAC Address)
System Name: Router
Device Port: eth 0/1 (Locally Assigned)
Holdtime: 38
Platform: NetVanta 3305
Software: Version: 08.00.22.sw1.D, Date: Mon Nov 01 10:28:55 2004
Capabilities: Bridge, Router
Enabled Capabilities: Router
Local Port: eth 0/3
Management Addresses:
Address Type: IP version 4, Address: 10.23.10.10
Interface Type: Interface Index, Interface Id: 2
The following example shows LLDP-MED capable neighbors connected to a device:
>enable
#show lldp neighbors med
Capability Codes: R - Router, B - Bridge, H - Host, D - DOCSIS Device,
W - WLAN Access Point, r - Repeater, T - Telephone
System Name
60000CRG0-35E
Command was introduced.
The realtime display parameter was introduced.
Command was expanded to include the modifiers begin, exclude, and
include.
Command was expanded to include the med parameter.
Command was expanded to include the Metro Ethernet Forum (MEF)
Ethernet interface.
Command was expanded to include the Gigabit Ethernet and Gigabit
Switchport interfaces.
Port ID TTL
Copyright © 2012 ADTRAN, Inc.
Enable Mode Command Set
terminal length <number> on
Cap. Platform Local Int
653
