Command Reference Guide
Usage Examples
The following example shows all QoS maps and all entries in those maps:
>enable
#show qos map
qos map priority
map entry 10
match IP packets with a precedence value of 6
priority bandwidth: 400 (kilobits/sec) burst: default
map entry 20
match ACL icmp
map entry 30
match RTP packets on even destination ports between 16000 and 17000
map entry 50
match ACL tcp
map entry 60
match IP packets with a dscp value of 2
set dscp value to 6
map entry 70
match NetBEUI frames being bridged by the router
priority bandwidth: 150 (kilobits/sec) burst: default
qos map tcp_map
map entry 10
match ACL tcp
priority bandwidth: 10 (kilobits/sec) burst: default
set precedence value to 5
map entry 20
match IP packets with a precedence value of 3
priority bandwidth: 50 (kilobits/sec) burst: default
The following example shows the QoS map named priority and all entries in that map:
>enable
#show qos map priority
qos map priority
map entry 10
match IP packets with a precedence value of 6
priority bandwidth: 400 (kilobits/sec) burst: default
map entry 20
match ACL icmp
map entry 30
match RTP packets on even destination ports between 16000 and 17000
map entry 50
match ACL tcp
map entry 60
match IP packets with a dscp value of 2
