ADTRAN AOS Version R10.1.0 Command Reference Manual page 748

Command Reference Guide
Functional Notes
Use the realtime argument for this command to display full-screen output in real time. Information is
continuously updated on the console until you either freeze the data (by pressing the F key) or exit
realtime mode (by pressing Ctrl-C). If there is not enough room on the screen for all available data, the
information will truncate at the bottom of the screen. In order to maximize the amount of data displayed,
increase the terminal length (using the terminal length command; refer to
page 837).
Usage Examples
The following is sample output from the show spanning-tree command:
>enable
#show spanning-tree
Spanning Tree enabled protocol ieee
Root ID Priority 32768
Address 00:a0:c8:00:88:41
We are the root of the spanning tree
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Bridge ID Priority 32768
Address 00:a0:c8:00:88:41
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Aging Time 300
Interface Role
eth 0/2 Desg
eth 0/3 Desg
eth 0/4 Desg
giga-eth 0/1 Desg
giga-eth 0/2 Desg
60000CRG0-35E
Sts Cost Prio. Nbr.
FWD 19 128.2
FWD 19 128.3
FWD 19 128.4
FWD 4 128.25
FWD 4 128.26
Copyright © 2012 ADTRAN, Inc.
Enable Mode Command Set
terminal length <number> on
Type
P2p
P2p
P2p
P2p
P2p
748
