Command Reference Guide Enable Mode Command Set
The following is sample output for the debug ip packet vrf <name> command for the VRF named Red:
>enable
#debug ip packet vrf RED
IP: s=192.168.1.100 (eth 0/1.4) d=192.168.1.255 (Loopback), vrf=RED, rcvd
IP: s=192.168.1.101 (eth 0/1.4) d=192.168.1.1 (Loopback), vrf=RED, rcvd
IP: s=192.168.1.1 (Loopback) d=192.168.1.101 (eth 0/1.4) g=192.168.1.101, vrf=RED, forward
IP: s=192.168.1.100 (eth 0/1.4) d=192.168.1.1 (Loopback), vrf=RED, rcvd
IP: s=192.168.1.1 (Loopback) d=192.168.1.100 (eth 0/1.4) g=192.168.1.100, vrf=RED, forward
Where:
rcvd indicates the router received this packet.
The following is sample output for the debug ip packet any-vrf command:
>enable
#debug ip packet any-vrf
IP: s=192.168.1.15 (eth 0/1.1) d=192.168.1.1 (Loopback), rcvd
IP: s=192.168.1.1 (Loopback) d=192.168.1.15 (eth 0/1.1) g=192.168.1.15, forward
IP: s=192.168.1.101 (eth 0/1.4) d=255.255.255.255 (Loopback), vrf=RED, rcvd
IP: s=192.168.1.1 (Loopback) d=192.168.1.101 (eth 0/1.4) g=192.168.1.101, vrf=RED, forward
IP: s=192.168.2.33 (eth 0/1.3) d=192.168.2.1 (Loopback), vrf=BLU, rcvd
IP: s=192.168.2.1 (Loopback) d=192.168.2.33 (eth 0/1.3) g=192.168.2.33, vrf=BLU, forward
IP: s=192.168.1.101 (eth 0/1.4) d=192.168.1.1 (Loopback), vrf=RED, rcvd
IP: s=192.168.1.1 (Loopback) d=192.168.1.101 (eth 0/1.4) g=192.168.1.101, vrf=RED, forward
Where:
if the vrf=<name> statement is not present, the packet was present on the default VRF.
vrf=<name> indicates the nondefault VRF from which the packet was received.
forward indicates the router transmitted this packet.
g=x.x.x.x indicates the next-hop IP address to which the packet was forwarded.
