Command Reference Guide
hw-access-map <name>
Use the hw-access-map command to create and name a hardware access map. This command also enters
the map's configuration mode. Using the no form of this command deletes the hardware access map.
For a complete list of all hardware access map configuration commands, refer to the
Hardware ACL and Access Map Command Set on page
Syntax Description
<name>
Default Values
By default, all AOS security features are disabled, and there are no configured hardware access maps.
Command History
Release 17.6
Functional Notes
This command only creates an empty hardware access map, it does not configure it. For additional
hardware access map configuration commands and configuration parameters, refer to the
and Access Map Command Set on page 3109
online at https://supportforums.adtran.com
Usage Examples
The following example creates a hardware access map Map1 and enters the hardware access map
configuration mode:
(config)#hw-access-map Map1
(config-hw-access-map)#
Technology Review
Hardware access maps can only forward traffic. This action can be performed based on the criteria
outlined in a single IP hardware access control list (ACL), a single medium access control (MAC) hardware
ACL, or both. Like the hardware ACLs, the hardware access map will match traffic in top-down order.
If you configure the access map to reference a nonexistent IP or MAC hardware ACL, the ACL will be
created. Note that this newly created ACL will have permit any as the default entry because no other
entries are present.
60000CRG0-35E
Specifies the name of the hardware access map.
Command was introduced.
or the Hardware ACLs in AOS configuration guide available
(article number 3088).
Copyright © 2012 ADTRAN, Inc.
Global Configuration Mode Command Set
3109.
