ADTRAN AOS Version R10.1.0 Command Reference Manual page 376

Command Reference Guide
Command History
Release 9.3
Release 10.1
Release 12.1
Release 13.1
Release 14.1
Release 15.1
Release A1
Release A2
Release A2.04
Release A4.01
Release A4.05
Release A5.01
Usage Examples
The following example activates all debug messages associated with voice functionality:
>enable
#debug voice summary
The following is sample output from the debug voice paging-group command for paging group 6299:
>enable
#debug voice paging-group 6299
16:08:50:737 HPG.6299 rcvd: deliver from SB
16:08:50:738 HPG.6299 Undo of previous operation not required (RTP NAT Entry for 10.10.20.2:2228 not
found)
16:08:50:739 HPG.6299 Checking for internal Media Gateway IP Address
16:08:50:739 HPG.6299 Given RTP Channel is null, checking for hairpinned RTP Channel
16:08:50:739 HPG.6299 Unable to find hairpinned RTP Channel
16:08:50:739 HPG.6299 RTP Channel is NULL, Media Gateway must not be involved in call
16:08:50:739 HPG.6299 Checking need for firewall traversal
16:08:50:740 HPG.6299 Testing firewall policies
16:08:50:740 HPG.6299 NAT not required, no need for firewall traversal here
16:08:50:740 HPG.6299 sent: deliverResponse to SB
16:08:50:740 HPG.6299 In - State change >> Idle -> Ringing
60000CRG0-35E
Command was introduced.
Command was expanded to include more parameters.
Command was expanded to include more parameters.
Command was expanded to include more parameters.
Command was expanded to include more parameters.
Command was expanded to include more parameters.
Command was expanded to include the loopback parameter.
Command was expanded to include the conference local and dsp
parameters.
Command was expanded to include the erltool, paging-group, and
replication parameters.
Command was expanded to include the moh, findme-followme,
pickup-group, queue, and conference local parameters.
Command was altered to exclude the color and pickup-group parameters.
The color parameter is covered by the debug color command on
and the pickup-group parameter is covered using the debug voice
verbose command. Command was expanded to include the
services-interface and ring-group parameters.
Command was expanded to include the fax, detailed, and isu_cp_det
parameters.
Copyright © 2012 ADTRAN, Inc.
Enable Mode Command Set
page 231
376
