Command Reference Guide
debug ip pim-sparse register
Use the debug ip pim-sparse register command to display protocol-independent multicast (PIM) sparse
source registration messages. Debug messages are displayed (real time) to the terminal (or Telnet) screen.
Use the no form of this command to disable the debug messages. Variations of this command include:
debug ip pim-sparse register
debug ip pim-sparse register event
debug ip pim-sparse register event <multicast address>
debug ip pim-sparse register state
debug ip pim-sparse register state <multicast address>
Turning on a large amount of debug information can adversely affect the performance of
your unit.
Syntax Description
event
state
<multicast address>
Default Values
By default, all debug messages in AOS are disabled.
Command History
Release 11.1
Usage Examples
The following example activates all PIM sparse registration changes:
>enable
#debug ip pim-sparse register
18:14:22: PIMSM: Registered new source (10.100.13.240, 239.192.19.136) from 10.10.10.1
18:14:22: PIMSM: RegisterStop(10.100.13.240, 239.192.19.136) sent to 10.10.10.1
18:14:53: PIMSM: RegisterStop(10.100.13.240, 239.192.19.136) sent to 10.10.10.1
18:16:17: PIMSM: RegisterStop(10.100.13.240, 239.192.19.136) sent to 10.10.10.1
60000CRG0-35E
Optional. Displays PIM sparse register events.
Optional. Displays PIM sparse register state changes.
Optional. Specifies multicast group IP address to filter. The multicast group
IP address range is 244.0.0.0 to 239.255.255.255 or 224.0.0.0 /4.
Command was introduced.
Copyright © 2012 ADTRAN, Inc.
Enable Mode Command Set
