(unpacking) operations. Companding can be used when word packing or
unpacking is being used.
When serial port data packing is enabled, the transmit and receive inter-
rupts are generated for the 32-bit packed words, not for each 16-bit word.

When 16-bit received data is packed into 32-bit words and stored
in normal word space in processor internal memory, the 16-bit
words can be read or written with short word space addresses.

Data Type

The field of the
DTYPE
formats (for non-multichannel operation) shown in
field is reserved for I
selected for primary A channel, the secondary B channel performs a
zero-fill.

In Multichannel mode, channel B looks at
If
DTYPE[0]
If
DTYPE[0]
Table 9-3. DTYPE and Data Formatting (DSP Serial Mode)
DTYPE Data Formatting
00
01
10
11
ADSP-2126x SHARC Processor Hardware Reference
Control registers specifies one of four data
SPCTLx
2
S mode. In DSP Serial mode, if companding is
= 1 sign-extend
= 0 zero-fill
Right-justify, zero-fill unused MSBs
Right-justify, sign-extend into unused MSBs
Compand using -law (primary A channels only)
Compand using A-law (primary A channels only)
Serial Ports
Table 9-3. This bit
only.
XDTYPE[0]
9-41
