Core Registers
Table A-18. PSx, DMx, IOx, and EPx (Breakpoint) Registers (Cont'd)
Register
PMDAS
PMDAE
IOAS
IOAE
1 Group IA = 24-bit addresses, Groups DA and PA = 32-bit addresses,
Group I/O = 19-bit addresses.
Table A-19. EEMUSTAT (Breakpoint Status) Register Definitions
Bits Name
0 STATPA
1 STATDA0
2 STATDA1
3 STATIA0
4 STATIA1
5 STATIA2
A-56
Function
Program Data Address Start
Program Data Address End
I/O Address Start
I/O Address End
Function
Program memory Data Breakpoint Hit
1 = Program memory breakpoint occurs
0 = No program memory breakpoint occurs
Data Memory Breakpoint Hit
1 = Data memory #0 breakpoint occurs
0 = No data memory #0 breakpoint occurs
Data Memory Breakpoint Hit
1 = Data memory #1 breakpoint occurs
0 = No Data memory #1 breakpoint occurs
Instruction Address Breakpoint Hit
1 = Instruction address #0 breakpoint occurs
0 = no Instruction address #0 breakpoint occurs
Instruction Address Breakpoint Hit
1 = Instruction address #1 breakpoint occurs
0 = no Instruction address #1 breakpoint occurs
Instruction Address Breakpoint Hit
1 = Instruction address #2 breakpoint occurs
0 = no Instruction address #2 breakpoint occurs
ADSP-2126x SHARC Processor Hardware Reference
1
Group
PA
PA
I/O
I/O
1
1
1
1
1
1
