Table 3-17. Register-to-Register Moves – Complementary Pairs
Condition Condition
in PEx in PEy
AZx AZy
0 0
0 1
1 0
1 1
Example 4: Register-to-Memory Move – PEy Explicit Register
For the following instructions, the DSP is operating in SIMD mode and
registers in the PEy data register file are used as explicit registers. The data
movement resulting from the evaluation of the conditional test in the PEx
and PEy processing elements is shown in
IF EQ R9 = S2;
IF EQ PX1 = S2;
IF EQ USTAT1 = S2;
Table 3-18. Register-to-Register Moves – Complementary Register Pairs
Condition Condition
in PEx in PEy
AZx AZy
0 0
0 1
ADSP-2126x SHARC Processor Hardware Reference
Result
Explicit
No data move occurs
No data move to registers r9,
px1, and ustat1 occurs
r2 transfers to registers r9,
px1, and ustat1
r2 transfers to registers r9,
px1, and ustat1
Result
Explicit
No data move occurs
No data move to registers s9,
px and ustat1 occurs
Program Sequencer
Implicit
No data move occurs
s2 transfers to registers s9, px2 and
ustat2
No data move to s9, px2, or ustat2
occurs
s2 transfers to registers s9, px2, and
ustat2
Table 3-18.
Implicit
No data move occurs
r2 transfers to registers s9, px2,
and ustat2
3-41
