Table 9-10. SPORT DMA Parameter Registers Addresses (Cont'd)
Register
CPSP1A
IISP1B
IMSP1B
CSP1B
CPSP1B
Reserved
IISP2A
IMSP2A
CSP2A
CPSP2A
IISP2B
IMSP2B
CSP2B
CPSP2B
IISP3A
IMSP3A
CSP3A
CPSP3A
IISP3B
IMSP3B
CSP3B
CPSP3B
Reserved
IISP4A
IMSP4A
CSP4A
ADSP-2126x SHARC Processor Hardware Reference
Address DMA Channel
0xc4B 2
0xc4C 3
0xc4D 3
0xc4E 3
0xc4F 3
0x440 4
0x441 4
0x442 4
0x443 4
0x444 5
0x445 5
0x446 5
0x447 5
0x448 6
0x449 6
0x44A 6
0x44B 6
0x44C 7
0x44D 7
0x44E 7
0x44F 7
0x840 8
0x841 8
0x842 8
Serial Ports
SPORT Buffer
RXSP1A or TXSP1A
RXSP1B or TXSP1B
RXSP1B or TXSP1B
RXSP1B or TXSP1B
RXSP1B or TXSP1B
RXSP2A or TXSP2A
RXSP2A or TXSP2A
RXSP2A or TXSP2A
RXSP2A or TXSP2A
RXSP2B or TXSP2B
RXSP2B or TXSP2B
RXSP2B or TXSP2B
RXSP2B or TXSP2B
RXSP3A or TXSP3A
RXSP3A or TXSP3A
RXSP3A or TXSP3A
RXSP3A or TXSP3A
RXSP3B or TXSP3B
RXSP3B or TXSP3B
RXSP3B or TXSP3B
RXSP3B or TXSP3B
RXSP4A or TXSP4A
RXSP4A or TXSP4A
RXSP4A or TXSP4A
