Table A-14. FLAGS Register Bit Descriptions
Bits Name
0 FLG0
1 FLG0O
2 FLG1
3 FLG1O
4 FLG2
5 FLG2O
6 FLAG3
7 FLG3O
8 FLG4
9 FLG4O
10 FLG5
11 FLG5O
12 FLG6
13 FLG6O
14 FLG7
15 FLG7O
ADSP-2126x SHARC Processor Hardware Reference
Definition
FLAG0 Value. Indicates the state of the FLG0 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG0 Output Select. Selects the I/O direction for the FLG0 pin, the
flag is programmed as an output if set, (= 1) or input if cleared, (= 0).
FLAG1 Value. Indicates the state of the FLG1 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG1 Output Select. Selects the I/O direction for the FLG1 pin—an
output if set, (= 1) or input if cleared, (= 0).
FLAG2 Value. Indicates the state of the FLG2 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG2 Output Select. Selects the I/O direction for the FLG2 pin—out-
put if set, (= 1) or input if cleared, (= 0).
FLAG3 Value. Indicates the state of the FLAG3 pin—high (if set, = = 1)
or low if cleared, (= 0).
FLAG3 Output Select. Selects the I/O direction for the FLAG3 pin—
output if set, (= 1) or input if cleared, (= 0).
FLAG4 Value. Indicates the state of the FLAG4 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG4 Output Select. Selects the I/O direction for the FLAG4 pin—
output if set, (= 1) or input if cleared, (= 0).
FLAG5 Value. Indicates the state of the FLAG5 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG5 Output Select. Selects the I/O direction for the FLAG5 pin—
output if set, (= 1) or input if cleared, (= 0).
FLAG6 Value. Indicates the state of the FLAG6 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG6 Output Select. Selects the I/O direction for the FLAG6 pin—
output if set, (= 1) or input if cleared, (= 0).
FLAG7 Value. Indicates the state of the FLAG7 pin—high if set, (= 1) or
low if cleared, (= 0).
FLAG7 Output Select. Selects the I/O direction for the FLAG7 pin—
output if set, (= 1) or input if cleared, (= 0).
