Table 2-10. Shifter Instruction Summary (Cont'd)
Instruction
Rn = BCLR Rx BY Ry
Rn = BCLR Rx BY <data8>
Rn = BSET Rx BY Ry
Rn = BSET Rx BY <data8>
Rn = BTGL Rx BY Ry
Rn = BTGL Rx BY <data8>
BTST Rx BY Ry
BTST Rx BY <data8>
Rn = FDEP Rx BY Ry
Rn = FDEP Rx BY <bit6>:<len6>
Rn = Rn OR FDEP Rx BY Ry
Rn = Rn OR FDEP Rx BY <bit6>:<len6>
Rn = FDEP Rx BY Ry (SE)
Rn = FDEP Rx BY <bit6>:<len6> (SE)
Rn = Rn OR FDEP Rx BY Ry (SE)
Rn = Rn OR FDEP Rx BY <bit6>:<len6> (SE)
Rn = FEXT Rx BY Ry
Rn = FEXT Rx BY <bit6>:<len6>
Rn = FEXT Rx BY Ry (SE)
Rn = FEXT Rx BY <bit6>:<len6> (SE)
Rn = EXP Rx (EX)
Rn = EXP Rx
Rn = LEFTZ Rx
Rn = LEFTO Rx
Rn = FPACK Fx
Fn = FUNPACK Rx
ADSP-2126x SHARC Processor Hardware Reference
Processing Elements
ASTATx,y Flags
SZ SV
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* *
* 0
* 0
* *
* *
0 *
0 0
SS
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
*
*
0
0
0
0
2-37
