Analog Devices ADSP-21261 SHARC Hardware Reference Manual page 743

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
SRU_DAT4 (0x2445)
Reserved
IDP7_DAT_I
Input Data Port 7 Data Input
15 14 13 12 11 10
0
IDP5_DAT_I
Input Data Port 5 Data Input
Figure A-42. SRU_DAT4 Register
Table A-35. Group B Sources – Serial Data
Selection Code
000000 (0x0)
000001 (0x1)
000010 (0x2)
000011 (0x3)
000100 (0x4)
000101 (0x5)
000110 (0x6)
000111 (0x7)
001000 (0x8)
001001 (0x9)
001010 (0xA)
001011 (0xB)
001100 (0xC)
001101 (0xD)
001110 (0xE)
ADSP-2126x SHARC Processor Hardware Reference
0 0 0 0 0 0 0 0
9 8
0 0 0 0 0 0 0
Source Signal
DAI_PB01_O
DAI_PB02_O
DAI_PB03_O
DAI_PB04_O
DAI_PB05_O
DAI_PB06_O
DAI_PB07_O
DAI_PB08_O
DAI_PB09_O
DAI_PB10_O
DAI_PB11_O
DAI_PB12_O
DAI_PB13_O
DAI_PB14_O
DAI_PB15_O
Registers Reference
0 0 0 0 0 0 0
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0
Description
Select DAI Pin Buffer 1 as the source
Select DAI Pin Buffer 2 as the source
Select DAI Pin Buffer 3 as the source
Select DAI Pin Buffer 4 as the source
Select DAI Pin Buffer 5 as the source
Select DAI Pin Buffer 6 as the source
Select DAI Pin Buffer 7 as the source
Select DAI Pin Buffer 8 as the source
Select DAI Pin Buffer 9 as the source
Select DAI Pin Buffer 10 as the source
Select DAI Pin Buffer 11 as the source
Select DAI Pin Buffer 12 as the source
Select DAI Pin Buffer 13 as the source
Select DAI Pin Buffer 14 as the source
Select DAI Pin Buffer 15 as the source
0
IDP6_DAT_I
Input Data Port 6
Data Input
IDP4_DAT_I
Input Data Port 4
Data Input
A-121
