Table 9-5. SPORT Registers (Cont'd)
IOP Register
Address
0xC05 MT0CS0
0xC06 MT0CS1
0xC07 MT0CS2
0xC08 MT0CS3
0xC09 MR1CS0
0xC0A MR0CS1
0xC0B MR0CS2
0xC0C MR1CS3
0xC0D MT0CCS0
0xC0E MT0CCS1
0xC0F MT0CCS2
0xC10 MT0CCS3
0xC11 MR1CCS0
0xC12 MR1CCS1
0xC13 MR1CCS2
ADSP-2126x SHARC Processor Hardware Reference
Reset Description
0x0000 0000 SPORT0 Multichannel Transmit Select 0
(Channels 31–0)
0x0000 0000 SPORT0 Multichannel Transmit Select 1
(Channels 63–32)
0x0000 0000 SPORT0 Multichannel Transmit Select 2
(Channels 95–64)
0x0000 0000 SPORT0 Multichannel Transmit Select 3
(Channels 127–96)
0x0000 0000 SPORT1 Multichannel Receive Select 0
(Channels 31–0)
0x0000 0000 SPORT0 Multichannel Receive Select 1
(Channels 63–32)
0x0000 0000 SPORT0 Multichannel Receive Select 2
(Channels 95–64)
0x0000 0000 SPORT0 Multichannel Receive Select 3
(Channels 127–96)
0x0000 0000 SPORT0 Multichannel Transmit Compand Select 0
(Channels 31–0)
0x0000 0000 SPORT0 Multichannel Transmit Compand Select 1
(Channels 63–32)
0x0000 0000 SPORT0 multichannel transmit compand select 2
(Channels 95–64)
0x0000 0000 SPORT0 Multichannel Transmit Compand Select 3
(Channels 127–96)
0x0000 0000 SPORT1 Multichannel Receive Compand Select 0
(Channels 31–0)
0x0000 0000 SPORT1 Multichannel Receive Compand Select 1
(Channels 63–32)
0x0000 0000 SPORT1 Multichannel Receive Compand Select 2
(Channels 95–64)
