I/O Processor Registers

Timer Configuration Registers (TMxCTL)

All timer clocks are gated off when the specific timer's configuration regis-
ter is set to zero at system reset or subsequently reset by user programs.
These registers are shown in
15 14 13 12
IRQEN
Interrupt Enable
PRDCNT
Period Count
Figure A-68. TMxCTL Register
Table A-49. TMxCTL Register Bit Descriptions
Bit
1–0
2
3
4
A-158
Figure
11 10
9
8
7
6
Name
Definition
TIMODE
Timer Mode.
00 = Reset
01 = PWM_OUT mode (TIMODEPWM)
10 = WDTH_CAP mode (TIMODEW)
11 = EXT_CLK mode (TIMODEEXT)
PULSE
Pulse Edge Select.
1 = Positive active pulse
0 = Negative active pulse
PRDCNT
Period Count.
1 = Count to end of period
0 = Count to end of width
IRQEN
Interrupt Enable.
1 = Enable
0 = Disable
ADSP-2126x SHARC Processor Hardware Reference
A-68.
5
4
3
2
1
0
TIMODE (1–0)
Timer Mode
PULSE
Pulse Edge Select
