I/O Processor Registers
Table A-37. Group D Sources – Pin Signal Assignments (Cont'd)
Selection Code
010111 (0x17)
011000 (0x18)
011001 (0x19)
011010 (0x1A)
011011 (0x1B)
011100 (0x1C)
011101 (0x1D)
011110 (0x1E)
011111 (0x1F)
100000 (0x20)
100001 (0x21)
100010 (0x22)
100011 (0x23)
100100 (0x24)
100101 (0x25)
100110 (0x26)
100111 (0x27)
101000 (0x28)
101001 (0x29)
101010 (0x2A)
101011 (0x2B)
101100 (0x2C)
101101 (0x2D)
101110 (0x2E)
101111 (0x2F)
A-130
Source Signal
SPORT1_DB_O
SPORT2_DA_O
SPORT2_DB_O
SPORT3_DA_O
SPORT3_DB_O
SPORT4_DA_O
SPORT4_DB_O
SPORT5_DA_O
SPORT5_DB_O
SPORT0_CLK_O
SPORT1_CLK_O
SPORT2_CLK_O
SPORT3_CLK_O
SPORT4_CLK_O
SPORT5_CLK_O
SPORT0_FS_O
SPORT1_FS_O
SPORT2_FS_O
SPORT3_FS_O
SPORT4_FS_O
SPORT5_FS_O
TIMER0_O
TIMER1_O
TIMER2_O
FLAG10_O
ADSP-2126x SHARC Processor Hardware Reference
Description
Select SPORT 1B Data as the source
Select SPORT 2A Data as the source
Select SPORT 2B Data as the source
Select SPORT 3A Data as the source
Select SPORT 3B Data as the source
Select SPORT 4A Data as the source
Select SPORT 4B Data as the source
Select SPORT 5A Data as the source
Select SPORT 5B Data as the source
Select SPORT 0 Clock as the source
Select SPORT 1 Clock as the source
Select SPORT 2 Clock as the source
Select SPORT 3 Clock as the source
Select SPORT 4 Clock as the source
Select SPORT 5 Clock as the source
Select SPORT 0 Frame Sync as the source
Select SPORT 1 Frame Sync as the source
Select SPORT 2 Frame Sync as the source
Select SPORT 3 Frame Sync as the source
Select SPORT 4 Frame Sync as the source
Select SPORT 5 Frame Sync as the source
Select Timer 0 as the source
Select Timer 1 as the source
Select Timer 2 as the source
Select Flag 10 as the source
