Table A-38. Group E Sources – Miscellaneous Signals
Selection Code
00000 (0x0)
00001 (0x1)
00010 (0x2)
00011 (0x3)
00100 (0x4)
00101 (0x5)
00110 (0x6)
00111 (0x7)
01000 (0x8)
01001 (0x9)
01010 (0xA)
01011 (0xB)
01100 (0xC)
01101 (0xD)
01110 (0xE)
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
ADSP-2126x SHARC Processor Hardware Reference
Source Signal
DAI_PB01_O
DAI_P02_O
DAI_P03_O
DAI_P04_O
DAI_P05_O
DAI_P06_O
DAI_P07_O
DAI_P08_O
DAI_P09_O
DAI_P10_O
DAI_P11_O
DAI_P12_O
DAI_P13_O
DAI_P14_O
DAI_P15_O
DAI_P16_O
DAI_P17_O
DAI_P18_O
DAI_P19_O
Registers Reference
Description
Select DAI Pin Buffer 1 Output as the source
Select DAI Pin Buffer 2 Output as the source
Select DAI Pin Buffer 3 Output as the source
Select DAI Pin Buffer 4 Output as the source
Select DAI Pin Buffer 5 Output as the source
Select DAI Pin Buffer 6 Output as the source
Select DAI Pin Buffer 7 Output as the source
Select DAI Pin Buffer 8 Output as the source
Select DAI Pin Buffer 9 Output as the source
Select DAI Pin Buffer 10 Output as the
source
Select DAI Pin Buffer 11 Output as the
source
Select DAI Pin Buffer 12 Output as the
source
Select DAI Pin Buffer 13 Output as the
source
Select DAI Pin Buffer 14 Output as the
source
Select DAI Pin Buffer 15 Output as the
source
Select DAI Pin Buffer 16 Output as the
source
Select DAI Pin Buffer 17 Output as the
source
Select DAI Pin Buffer 18 Output as the
source
Select DAI Pin Buffer 19 Output as the
source
A-135
