Making Connections in the SRU

Table 12-6. Group E Sources – Misc. Assignment

Signal Inputs

DAI Pin Register

SRU_EXT_MISCA

SRU_EXT_MISCB

INV_MISCA4_I

INV_MISCA5_I

ADSP-2126x SHARC Processor Hardware Reference

Signal Sources

• 20 External Pins (DAI_PBxx_O)

• 3 Timers (TIMERx_O)

• 1 IDP Parallel Input Strobe Output

(PDAP_STRB_O)

• 2 Clock A/B Outputs (PCG_CLKx_O)

• 2 PCG Frame Sync A/B Outputs

• 2 Logic Level (High/Low) Options
