ADSP-2126x Memory Map

PX1 = R0; /* R0 32-bit explicit move to PX1,
PX = R0; /* R0 40-bit explicit move to PX,
Instruction Example
PX = USTAT1;
PX1
64 bits
63 31
64 bits
63 31
USTAT1
Figure 5-6. PX Register-to-Internal Memory Transfers Over the PM or
DM DATA Bus
ADSP-2126x Memory Map
The ADSP-2126x family is composed of a variety of models that have
varying amounts of RAM and/or ROM memory. However, in general,
there are two memory spaces: internal memory space and external (DMA)
memory space. These spaces have these definitions:
• Internal memory space. This space ranges from address 0x00 0000
through 0x1F FFFF. Internal memory space refers to the DSP's
on-chip RAM, on-chip ROM, and memory-mapped registers.
• External (DMA) memory. For information on external DMA
memory space please refer to the product-specific data sheet.
5-10
and S0 32-bit implicit move to PX2 */
but no implicit move for S0 */
0 63
0 63
ADSP-2126x SHARC Processor Hardware Reference
PX2
64 bits
31 0
64 bits
31 0
USTAT2
