Group B Connections – Data Signals
Group B connections, shown in
serial data inputs. The serial data inputs to both the A and B channels of
the SPORTs and to each of the eight IDP channels are selected from the
list of Group B sources and set in the Group B registers. When a SPORT
is not configured to receive, the data source set here is ignored. Likewise,
when channel 0 of the IDP is used for the PDAP, the serial data source set
here is ignored.
Table 12-3. Group B Sources – Serial Data
Signal Inputs
Serial Data Register
SRU_DAT0
SRU_DAT1
SRU_DAT2
SRU_DAT3
SRU_DAT4
ADSP-2126x SHARC Processor Hardware Reference
Table
Bit field
SPORT0_DA_I
SPORT0_DB_I
SPORT1_DA_I
SPORT1_DB_I
SPORT2_DA_I
SPORT2_DB_I
SPORT3_DA_I
SPORT3_DB_I
SPORT4_DA_I
SPORT4_DB_I
SPORT5_DA_I
SPORT5_DB_I
IDP0_DAT_I
IDP1_DAT_I
IDP2_DAT_I
IDP3_DAT_I
IDP4_DAT_I
IDP5_DAT_I
IDP6_DAT_I
IDP7_DAT_I
Digital Audio Interface
12-3, are used to route signals to
Signal Sources
• 20 External Pins (DAI_PBxx_O)
• 12 Serial Port x Data Outs
(SPORTx_DB_O)
• 2 Logic Level (High/Low) Options
12-19
