Table A-36. Group C Sources – Frame Sync (Cont'd)
Selection Code
00011 (0x3)
00100 (0x4)
00101 (0x5)
00110 (0x6)
00111 (0x7)
01000 (0x8)
01001 (0x9)
01010 (0xA)
01011 (0xB)
01100 (0xC)
01101 (0xD)
01110 (0xE)
01111 (0xF)
10000 (0x10)
10001 (0x11)
10010 (0x12)
10011 (0x13)
10100 (0x14)
10101 (0x15)
10110 (0x16)
10111 (0x17)
11000 (0x18)
11001 (0x19)
11010 (0x1A)
11011 (0x1B)
ADSP-2126x SHARC Processor Hardware Reference
Source Signal
DAI_PB04_O
DAI_PB05_O
DAI_PB06_O
DAI_PB07_O
DAI_PB08_O
DAI_PB09_O
DAI_PB10_O
DAI_PB11_O
DAI_PB12_O
DAI_PB13_O
DAI_PB14_O
DAI_PB15_O
DAI_PB16_O
DAI_PB17_O
DAI_PB18_O
DAI_PB19_O
DAI_PB20_O
SPORT0_FS_O
SPORT1_FS_O
SPORT2_FS_O
SPORT3_FS_O
SPORT4_FS_O
SPORT5_FS_O
Reserved
Reserved
Registers Reference
Description
Select DAI Pin Buffer 4 as the source
Select DAI Pin Buffer 5 as the source
Select DAI Pin Buffer 6 as the source
Select DAI Pin Buffer 7 as the source
Select DAI Pin Buffer 8 as the source
Select DAI Pin Buffer 9 as the source
Select DAI Pin Buffer 10 as the source
Select DAI Pin Buffer 11 as the source
Select DAI Pin Buffer 12 as the source
Select DAI Pin Buffer 13 as the source
Select DAI Pin Buffer 14 as the source
Select DAI Pin Buffer 15 as the source
Select DAI Pin Buffer 16 as the source
Select DAI Pin Buffer 17 as the source
Select DAI Pin Buffer 18 as the source
Select DAI Pin Buffer 19 as the source
Select DAI Pin Buffer 20 as the source
Select SPORT 0 Frame Sync as the source
Select SPORT 1 Frame Sync as the source
Select SPORT 2 Frame Sync as the source
Select SPORT 3 Frame Sync as the source
Select SPORT 4 Frame Sync as the source
Select SPORT 5 Frame Sync as the source
A-125
