Loops and Sequencing
Table 3-12. Pipelined Execution Cycles for Two Instruction Counterbased
Loop with Two Iterations
Cycles 1
Execute 1
N
Decode N + 1
Fetch N + 2
N is the loop start instruction and N + 3 is the instruction after the loop.
1. Loop count (LCNTR) equals 2
2. PC Stack supplies loop start address
3. Count expired tests true
4. Loop iteration aborts; PC and loop stacks pop
Table 3-13. Pipelined Execution Cycles for Two Instruction Counterbased
Loop with One Iteration (Two Overhead Cycles)
Cycles 1
Execute 1
N
Decode N + 1
Fetch N + 2
N is the loop start instruction and N + 3 is the instruction after the loop.
1. Loop count (LCNTR) equals 1
2. PC Stack supplies loop start address
3. Count expired tests true
4. Loop iteration aborts; PC and loop stacks pop; N + 1 suppressed
5. N + 2 suppressed
Processing of an interrupt that occurs during the last iteration of a one
instruction loop is delayed by one cycle when:
• the loop executes once or twice,
• a two instruction loop executes once, or
• a cycle follows one of these loops.
