I/O Processor Registers
Table A-21. I/O Processor Registers (Cont'd)
Register Group
Serial Port (SP)
Registers
A-64
IOP Registers
IISP0A, IISP0B, IMSP0A, IMSP0B, CSP0A, CSP0B, CPSP0A, CPSP0B,
IISP1A, IISP1B, IMSP1A, IMSP1B, CSP1A, CSP1B, CPSP1A, CPSP1B,
IISP2A, IISP2B, IMSP2A, IMSP2B, CSP2A, CSP2B, CPSP2A, CPSP2B,
IISP3A, IISP3B, IMSP3A, IMSP3B, CSP3A, CSP3B, CPSP3A, CPSP3B,
IISP4A, IISP4B, IMSP4A, IMSP4B, CSP4A, CSP4B, CPSP4A, CPSP4B,
IISP5A, IISP5B, IMSP5A, IMSP5B, CSP5A, CSP5B, CPSP5A, CPSP5B
RXSP0A, RXSP0B, TXSP0A, TXSP0B, SPCTL0, DIV0, MT0CS0,
MT0CCS0, MT0CS1, MT0CCS1, MT0CS2, MT0CCS2, MT0CS3,
MT0CCS3
RXSP1A, RXSP1B, TXSP1A, TXSP1B, SPCTL1, DIV1, MR1CS0,
MR1CCS0, MR1CS1, MR1CCS1, MR1CS2, MR1CCS2, MR1CS3,
MR1CCS3
RXSP2A, RXSP2B, TXSP2A, TXSP2B, SPCTL2, DIV2, MT2CS0,
MT2CCS0, MT2CS1, MT2CCS1, MT2CS2, MT2CCS2, MT2CS3,
MT2CCS3
RXSP3A, RXSP3B, TXSP3A, TXSP3B, SPCTL3, DIV3, MR3CS0,
MR3CCS0, MR3CS1, MR3CCS1, MR3CS2, M3CCS2, MR3CCS2,
MR3CS3, MR3CCS3
RXSP4A, RXSP4B, TXSP4A, TXSP4B, SPCTL4, DIV4, MT4CS0,
MT4CCS0, MT4CS1, MT4CCS1, MT4CS2, MT4CCS2, MT4CS3,
MT4CCS3
RXSP5A, RXSP5B, TXSP5A, TXSP5B, SPCTL5, DIV5, MR5CS0,
MR5CCS0, MR5CS1, MR5CCS1, MR5CS2, MR5CCS2, MR5CS3,
MR5CCS3
SPMCTL01, SPMCTL23, SPMCTL45
